Levelling foot VULCANIZED stainless steel, Ø 100 mm, M16 x 150 mm, NBR
EAN
4061408017584
Type
45825106
Introducing the VULCANIZED Stainless Steel Levelling Foot, designed for precision and stability. With a robust static load capacity of 15,000 N, it features a 100 mm diameter base, M16 x 150 mm threaded spindle, and a 10° articulated screw for optimal leveling on uneven surfaces. Ideal for demanding engineering applications.
| Quantity | Price |
|---|---|
| From 1 |
€15.15*
|
| From 13 |
€14.23*
|
| From 25 |
€13.31*
|
| From 50 |
€12.67*
|
85 on stock, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Footplate material: | Stainless steel |
| Anti-slip: | NBR black |
| Ø range base plate (mm): | 91-110 |
| Material spindle: | Stainless steel |
| Ø spindle (mm): | 16 |
| Spindle length (mm): | 150 |
| Balancing angle: | 10° |
Technical drawing
Levelling foot VULCANIZED stainless steel, Ø 100 mm, M16 x 150 mm, Stainlees steel, Total height 192 mm, Articulated screw 10°, Antislip NBR black, Static load 15.000 N
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
Download data sheet
Download STP file as ZIP
Go to Cadenas-Partcommunity
Certificates & declarations of conformity
