Clamp body freewheel unit Ø 50 X Ø 110 TFS50 TSUBAKI
EAN
4061408054398
Type
37TFS50
The TFS50 clamp body freewheel unit features an inner diameter of 50 mm and an outer diameter of 110 mm, delivering high torque capacity up to 3000 Nm. Optimal for precise engineering applications.
| Quantity | Price |
|---|---|
| From 1 |
€336.47*
|
| From 4 |
€321.47*
|
| From 50 |
€310.75*
|
Currently sold out, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Ø Shaft: | 50 |
| Torque Nm: | 701 - 3000 |
| Centrifugal force lifting: | No |
| Type/Variant: | TFS |
| Bearing: | No |
Technical drawing
Clamp body freewheel unit, inner Ø 50 mm H7, outer Ø 110 mm width 40 mm, Torque 1124, Nm keyway in inner 14 x 2,1 mm, with vertical keyway on outer ring
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
