Clamp body freewheel unit Ø 60 X Ø 130 TFS60 TSUBAKI
EAN
4061408042456
Type
37TFS60
Introducing the TFS60 Clamp Body Freewheel Unit, engineered for precision with an inner diameter of 60 mm and a robust torque capacity of 1975 Nm. Ideal for demanding applications.
| Quantity | Price |
|---|---|
| From 1 |
€510.11*
|
| From 4 |
€487.37*
|
| From 50 |
€471.12*
|
Currently sold out, Refill time: 5 days
Our payment methods:
Invoice
Product properties
| Ø Shaft: | 60 |
| Torque Nm: | 701 - 3000 |
| Centrifugal force lifting: | No |
| Type/Variant: | TFS |
| Bearing: | No |
Technical drawing
Clamp body freewheel unit, inner Ø 60 mm H7, outer Ø 130 mm width 46 mm, Torque 1975 Nm, keyway in inner ring 18 x 2,3 mm, with vertical keyway on outer ring
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
