Clamp body freewheel unit Ø 20 X Ø 52 TFS20 TSUBAKI
EAN
4061408034611
Type
37TFS20
The Tsubaki TFS20 Clamp Body Freewheel Unit features a compact design with an inner diameter of 20 mm and an outer diameter of 52 mm. Engineered for superior torque performance up to 84 Nm, this unit is ideal for precision applications requiring reliable motion control.
| Quantity | Price |
|---|---|
| From 1 |
€115.90*
|
| From 4 |
€110.73*
|
| From 50 |
€107.04*
|
1 on stock, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Ø Shaft: | 20 |
| Torque Nm: | 1 - 150 |
| Centrifugal force lifting: | No |
| Type/Variant: | TFS |
| Bearing: | No |
Technical drawing
Clamp body freewheel unit, inner Ø 20 mm H7, outer Ø 52 mm width 21 mm, Torque 84 Nm, keyway in inner ring 6 x 1,6 mm, with vertical keyway on outer ring
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
