Poly-steel chain 40-1 ANSI, 1/2" x 5/16", DIN 8188, lube-free, POM/ VA, pack 3,05 M.
EAN
4061408124329
Type
302RF40-1MPC
Discover the TSUBAKI 40-1 ANSI roller chain, a robust, lub-free solution with poly-steel construction, compliant with DIN 8188, ideal for efficient and hygienic transmissions.
| Quantity | Price | Base price |
|---|---|---|
| From 1 |
€158.06*
|
€51.82* / 1 metres |
| From 3 |
€155.53*
|
€50.99* / 1 metres |
| From 10 |
€154.27*
|
€50.58* / 1 metres |
| From 20 |
€151.74*
|
€49.75* / 1 metres |
Currently sold out, Refill time: 8 days
Our payment methods:
Invoice
Prepayment
PayPal
Skip product gallery
Accessories
Spring clip conn.link poly-steel chain 40-1 ANSI, 1/2 " x 5/16", corrosion resistant, DIN 8188
From
€6.01*
Type No.:
312RF40PC
Product properties
| Product family: | VA/POM PC |
| Abbreviation: | RS 35 A 3/8 x 3/16 |
| DIN standard: | DIN 8188 |
| Type: | Simplex |
| Pitch/Pitch (mm): | 12,70 |
| Roll Ø (mm): | 7,92 |
| Inner width (mm): | 7,95 |
| Hygiene: | Yes |
Drawing
Poly-steel chain 40-1 ANSI, 1/2" x 5/16", DIN 8188, lube-free, POM/ VA, pitch 12,7 mm, inner width 7,95 mm, sleeve-Ø 7,92 mm, TSUBAKI, POM-inner link, SS- outer link (AISI 304), package 3,05 M. incl. conn.link
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
