Roller chain 10 B-2, 5/8" x 3/8", Standard, Duplex, straight links, DIN 8187, pack 5 M.
EAN
4061408079704
Type
301RF10B2M
Optimize your machinery with the RS 10 B-2 roller chain, featuring a robust duplex design, precise dimensions, and compliance with DIN 8187 standards. Pack of 5 meters includes connection link.
| Quantity | Price | Base price |
|---|---|---|
| From 1 |
€299.69*
|
€59.94* / 1 metres |
| From 3 |
€294.89*
|
€58.98* / 1 metres |
| From 10 |
€292.50*
|
€58.50* / 1 metres |
| From 20 |
€287.70*
|
€57.54* / 1 metres |
Currently sold out, Refill time: 8 days
Our payment methods:
Invoice
Accessories
Reinforced spring clip conn.link 10 B-2, 5/8" x 3/8", Standard, Duplex, DIN 8187
From
€5.64*
Type No.:
311RF10B2
Product properties
| Product family: | Steel |
| Abbreviation: | RS 10 B 5/8 x 3/8 |
| Roll Ø (mm): | 10,16 |
| Type: | Duplex |
| Inner width (mm): | 9,65 |
| Pitch/Pitch (mm): | 15,88 |
| DIN standard: | DIN 8187 |
Drawing
Roller chain 10 B-2, 5/8" x 3/8", Standard steel chain, Duplex version, DIN 8187, straight links, pitch 15,88 mm, inner width 9,65 mm, roller-Ø 10,16 mm, TSUBAKI, package 5 M. incl. conn.link
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
