Levelling foot MASSIV Steel, Ø 100 mm, M16 x 75 mm, yellow
EAN
4061408041473
Type
45810764
Discover the MASSIV Steel Levelling Foot, featuring a robust design with a diameter of 100 mm and an M16 x 75 mm threaded spindle. With a static load capacity of 35,000 N and a 30° articulated screw, it ensures stability and precision for your engineering applications. Ideal for demanding industrial environments.
| Quantity | Price |
|---|---|
| From 1 |
€23.69*
|
| From 5 |
€22.69*
|
| From 15 |
€21.97*
|
| From 50 |
€21.68*
|
Currently sold out, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Footplate material: | Steel |
| Anti-slip: | No |
| Ø range base plate (mm): | 91-110 |
| Vibration damping: | no |
| Material spindle: | Steel |
| Ø spindle (mm): | 16 |
| Spindle length (mm): | 75 |
| Balancing angle: | 30° |
| Hygiene: | No |
Technical drawing
Levelling foot MASSIV Steel, Ø 100 mm, M16 x 75 mm, Galvanized steel, Total height 118 mm, Articulated screw 30°, yellow painted, Static load 35.000 N
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
Download data sheet
Download STP file as ZIP
Go to Cadenas-Partcommunity
Certificates & declarations of conformity
