Levelling foot MASSIV Steel, Ø 80 mm, M14 x 50 mm, NBR
EAN
4061408117383
Type
45815413/G
Introducing the MASSIV Steel Levelling Foot: engineered for stability with an 80 mm diameter and M14 x 50 mm threaded spindle, it supports static loads up to 20,000 N, featuring a black NBR anti-slip base for enhanced safety.
| Quantity | Price |
|---|---|
| From 1 |
€13.02*
|
| From 5 |
€12.47*
|
| From 15 |
€12.07*
|
| From 50 |
€11.91*
|
Currently sold out, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Footplate material: | Steel |
| Anti-slip: | NBR black |
| Ø range base plate (mm): | 71-90 |
| Material spindle: | Steel |
| Ø spindle (mm): | 14 |
| Spindle length (mm): | 50 |
| Balancing angle: | 5° |
Technical drawing
Levelling foot MASSIV Steel, Ø 80 mm, M14 x 50 mm, Galvanized steel, Total height 72 mm, Articulated screw 5°, Antislip NBR black, Static load 20.000 N
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
Download data sheet
Download STP file as ZIP
Go to Cadenas-Partcommunity
Certificates & declarations of conformity
