Levelling foot VULCANIZED stainless steel, Ø 80 mm, M12 x 150 mm, Lug, NBR
EAN
4061408027361
Type
45825006/12/BF/F
Discover our VULCANIZED stainless steel leveling foot with an 80 mm diameter, M12 x 150 mm threaded rod, and NBR anti-slip feature. Designed for robust support with a static load capacity of 10,000 N, it ensures precision and stability in dynamic applications.
| Quantity | Price |
|---|---|
| From 1 |
€14.50*
|
| From 13 |
€13.62*
|
| From 25 |
€12.75*
|
| From 50 |
€12.13*
|
25 on stock, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Footplate material: | Stainless steel |
| Anti-slip: | NBR black |
| Ø range base plate (mm): | 71-90 |
| Ground fastening: | 1 mounting lug |
| Vibration damping: | no |
| Material spindle: | Stainless steel |
| Ø spindle (mm): | 12 |
| Spindle length (mm): | 150 |
| Balancing angle: | 10° |
| Hygiene: | No |
Technical drawing
Levelling foot VULCANIZED stainless steel, Ø 80 mm, M12 x 150 mm, Stainlees steel, Total height 188 mm, Articulated screw 10°, Lug Ø 15 mm, Antislip NBR black, Static load 10.000 N
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
Download data sheet
Download STP file as ZIP
Go to Cadenas-Partcommunity
Certificates & declarations of conformity
