Levelling foot PA, Ø 83 mm, M16 x 200 mm Stainless steel, Drills, NBR
EAN
4061408013173
Type
45810087
Optimize your equipment's stability with our stainless steel leveling foot, featuring a 83 mm diameter polyamide base and articulated screw for a 30° adjustment. Static load capacity of 20,000 N.
| Quantity | Price |
|---|---|
| From 1 |
€10.32*
|
| From 5 |
€9.22*
|
| From 15 |
€8.24*
|
| From 50 |
€8.07*
|
Currently sold out, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Footplate material: | Plastic |
| Anti-slip: | NBR black |
| Ø range base plate (mm): | 71-90 |
| Ground fastening: | 2 mounting holes |
| Material spindle: | Stainless steel |
| Ø spindle (mm): | 16 |
| Spindle length (mm): | 200 |
| Balancing angle: | 30° |
Technical drawing
Levelling foot Polyamide, Ø 83 mm, M16 x 200 mm, Stainlees steel, Total height 245 mm, Articulated screw 30°, Bore holes Ø 8,5 mm, Antislip NBR black, Static load 20.000 N
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
Download data sheet
Go to Cadenas-Partcommunity
Certificates & declarations of conformity
