Levelling foot MASSIV Stainless Steel, Ø 50 mm, M12 x 50 mm, NBR
EAN
4061408070770
Type
45815005/50
Discover the MASSIV Stainless Steel Levelling Foot, designed for precision stability with a 50 mm diameter and a static load capacity of 12,000 N. Its articulated screw allows for a 5° angle adjustment, while the NBR rubber base ensures reliable anti-slip functionality. Perfect for engineers and manufacturers seeking durable and adjustable solutions.
| Quantity | Price |
|---|---|
| From 1 |
€12.09*
|
| From 13 |
€11.36*
|
| From 25 |
€10.63*
|
| From 50 |
€10.12*
|
Currently sold out, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Footplate material: | Stainless steel |
| Anti-slip: | NBR black |
| Ø range base plate (mm): | 41-50 |
| Material spindle: | Stainless steel |
| Ø spindle (mm): | 12 |
| Spindle length (mm): | 50 |
| Balancing angle: | 5° |
Technical drawing
Levelling foot MASSIV Stainless Steel, Ø 50 mm, M12 x 50 mm, Stainlees steel, Total height 75 mm, Articulated screw 5°, Antislip NBR black, Static load 12.000 N
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
Download data sheet
Download STP file as ZIP
Go to Cadenas-Partcommunity
Certificates & declarations of conformity
