Levelling foot TEKNO-HYGIENIC 3-A, Ø 100 mm Stainless steel, M30 x 185 mm, Lug, EPDM
EAN
4061408128938
Type
45827674F/3A
Discover the TEKNO-HYGIENIC 3-A leveling foot, featuring a robust stainless steel construction, superior load capacity of 25,000 N, and certified hygiene standards—perfect for demanding engineering applications.
| Quantity | Price |
|---|---|
| From 1 |
€59.19*
|
| From 13 |
€57.90*
|
| From 41 |
€57.04*
|
Currently sold out, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Footplate material: | Stainless steel |
| Anti-slip: | EPDM blue |
| Ø range base plate (mm): | 91-110 |
| Material spindle: | Stainless steel |
| Ø spindle (mm): | 30 |
| Spindle length (mm): | 185 |
| Balancing angle: | 15° |
| Hygiene: | Yes |
| Hygiene certification: | 3-A Sanitary Standard |
Technical drawing
Levelling foot TEKNO-HYGIENIC 3-A, Ø 100 mm Stainless steel, M30 x 185 mm, Stainlees steel, Total height 241 mm, Articulated screw 15°, Adjustment range 65 mm, Bushing 85 mm, Lug Ø 15 mm, Antislip EPDM blue, Static load 25.000 N
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
Download data sheet
Download STP file as ZIP
Go to Cadenas-Partcommunity
Certificates & declarations of conformity
