Levelling foot TEKNO-HYGIENIC 3-A, Ø 80 mm Stainless steel, M16 x 140 mm, EPDM
EAN
4061408128235
Type
45827640/3A
Optimize your equipment stability with the TEKNO-HYGIENIC 3-A leveling foot. Crafted from stainless steel, it offers a 15° adjustment angle, a static load capacity of 20,000 N, and is 3-A certified for hygiene compliance.
| Quantity | Price |
|---|---|
| From 1 |
€39.70*
|
| From 13 |
€38.84*
|
| From 41 |
€38.26*
|
Currently sold out, Refill time: 5 days
Our payment methods:
Invoice
Prepayment
PayPal
Product properties
| Footplate material: | Stainless steel |
| Anti-slip: | EPDM blue |
| Ø range base plate (mm): | 71-90 |
| Material spindle: | Stainless steel |
| Ø spindle (mm): | 16 |
| Spindle length (mm): | 140 |
| Balancing angle: | 15° |
| Hygiene: | Yes |
| Hygiene certification: | 3-A Sanitary Standard |
Technical drawing
Levelling foot TEKNO-HYGIENIC 3-A, Ø 80 mm Stainless steel, M16 x 140 mm, Stainlees steel, Total height 193 mm, Articulated screw 15°, Adjustment range 45 mm, Bushing 60 mm, Antislip EPDM blue, Static load 20.000 N
We develop customised components exactly as you need them for your application.
Technical documentation
In this section you will find all relevant documents & links for your documentation::
Download data sheet
Download STP file as ZIP
Go to Cadenas-Partcommunity
Certificates & declarations of conformity
