Sprockets for modular belts, straight running

These sprockets have been specially developed for straight-running modular belts. They enable precise power transmission and ensure that the conveyor belts run reliably. Their precise gearing ensures optimum meshing and low-wear operation.

These sprockets have been specially developed for straight-running modular belts. They enable precise power transmission and ensure that the conveyor belts run reliably. Their precise gearing ensures optimum meshing and low-wear operation.

These sprockets have been specially developed for straight-running modular belts. They enable precise power transmission and ensure that the conveyor belts run reliably. Their precise gearing ensures optimum meshing and low-wear operation.

Compatible with all common belt series and pitches

MOVET sprockets are precisely matched to a wide range of modular belt series, including 06 4xx, 12 4xx, 25 4xx, 25 8xx, 50 4xx, 50 9xx and more. The product range covers standard pitches of 6.25 mm, 12.5 mm, 25 mm, 50 mm and 75 mm, making the sprockets fully compatible with most straight-running plastic conveyor belts on the market.

Flexible configurations – multiple tooth counts and pitch diameters

The MOVET range includes sprockets with 6 to 48 teeth, allowing the drive geometry to be tailored to your system’s speed, torque and belt tension requirements. Depending on the model, the pitch diameter ranges from 40 mm to 288 mm, ensuring a perfect fit for everything from compact belt conveyors to heavy-duty transport systems.

Wide range of bore types – for easy mounting on shafts

MOVET sprockets are available with numerous bore configurations, including both round and square options: Ø 20, Ø 25, Ø 30, Ø 40, Ø 60 mm as well as VK 25, VK 40, VK 60, VK 80, VK 90. This makes it easy to install the sprockets onto existing drive shafts or hubs with secure, play-free alignment – ensuring efficient torque transfer and long service life.

Material selection: PA, POM and PP – tailored to your environment

MOVET sprockets are manufactured in high-performance plastics: PA (polyamide), POM (polyoxymethylene) and PP (polypropylene). PA provides excellent mechanical strength and dimensional stability. POM offers superior sliding and wear resistance. PP is lightweight and highly resistant to chemicals. This allows the sprockets to be used in a wide range of industries – from food processing to general automation.

Color coding for fast identification and hygiene compliance

Depending on the material and application, MOVET offers sprockets in natural, blue and white. The blue version is particularly suited for hygiene-critical applications, as it enables easy visual detection in the food sector. Color-coded sprockets also help with system classification during maintenance or belt changes.

Precision gearing for smooth, low-wear performance

The accurate tooth profile of every MOVET sprocket ensures optimum meshing with the modular belt. This reduces noise, prevents belt misalignment, and minimizes wear – even under continuous operation. The result is longer belt life, improved energy efficiency and consistent performance in conveyor systems.

MOVET – your expert for modular conveyor drive components

As a specialist in modular conveyor systems, MOVET offers not only the belts themselves but also all associated drive components. Our sprockets for straight-running modular belts are the result of in-depth engineering, practical experience and a consistent focus on quality. Discover the full MOVET range at movet.eu and find the right sprocket for your conveyor system.
